Wallbox eHOME INSTRUCTION & INSTALLATION MANUAL
37
13.1 CONNNECTIONS OF eHOME BeON
1. EV tethered cable
2. Output contactor
3. Main board
4. Current limit selector
5. Rear cover
6. RGB LEDs
7. Input terminals
8. Heater*
9. Power supply line
10. eHOME BeON
Negative / Pin 2S1
11. eHOME BeON
Positive / Pin 2S2
* Optional depending on the model
