8 INSIDE PRODUCT VIEW
1. EV tethered cable
2. Output contactor
3. Main board
4. Current limit selector
5. Rear cover
6. RGB LEDs
7. Input terminals
8. Heater*
9. Power supply line
5
4
2
7
8
9
6
1
3
* Optional depending on the model
