Wallbox eHOME INSTRUCTION & INSTALLATION MANUAL
5 INSTALLATION GUIDELINES
5.1 PREFACE
THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT
SAFETY INFORMATION IN THIS DOCUMENT
ELECTRIC RISK!
Take precautions to make the electrical connection
inside the unit.
The unit must be disconnected from any power supply
during the commissioning.
ATTENTION!
Damage to the property can occur if appropiate
precautions are not taken.
This section provides the commissioning information for Wallbox eHOME series, where is
described the electrical components inside the charging station and a step-by-step
installation procedure.
Standards & directives
• Complies with IEC 61851, Electric vehicle conductive charging system (IEC
61851-1, IEC 61851-22).
• Complies with IEC 62196, Plugs, socket-outlets, vehicle couplers and vehicle
inlets (IEC 62196-1 and IEC 62196-2).
• Directives: 2014/35/UE, LVD; 2014/30/UE, EMC.
