Wallbox eHOME INSTRUCTION & INSTALLATION MANUAL
19
STEP
ACTION
2.
Using a screw driver, put it into the indicated marks, at the bottom of the box, and
start removing the frame doing click at the bottom.
Beware of not breaking the plastic of the
frame with the screw driver.
CLICK!
