Wallbox eHOME INSTRUCTION & INSTALLATION MANUAL
28
3.
a) Use Ø 6 drill size to make the 3 holes into the wall.
b) Install the anchor according to the surface material.
4.
• Use a screw driver to fix the unit on the wall (recommended screw
dimensions: 3x45mm)
• Use only the unit holes indicated in the above picture to fix the unit on the
wall. Do not make any other holes on the housing; otherwise the water can
enter the unit when it rains.
All screws and wall plugs needed to attach
the unit to the wall are not included.
.
a
)
b
b
