Wallbox eHOME INSTRUCTION & INSTALLATION MANUAL
32
STEP
ACTION
2.
Put the frame back, from the top to the bottom of the box, ensuring it does click at
the six points shown in the picture.
Be sure that the frame is properly adjusted to
the front cover in order to preserve the IP of
the unit.
CLICK!
CLICK!
CLICK!
CLICK!
CLICK!
CLICK!
1
2
