Cisco 7811 User Manual

Transfers a call.Transfer button7
Toggles the speakerphone on or off. When the speakerphone is on, the
button is lit.
Speakerphone button8
Toggles the microphone on or off. When the microphone is muted, the
button is lit.
Mute button9
Allows you to dial phone numbers, enter letters, and select menu items
(by entering the item number).
Keypad10
Controls the handset and speakerphone volume (off-hook) and the ringer
volume (on-hook).
Volume button
11
Opens or closes the Directories menu. Use the Contacts button to access
personal and corporate directories.
Contacts button12
Opens or closes the Applications menu. Use the Applications button to
access call history, user preferences, phone settings, accessories, subscribed
phone services, and phone model information.
Applications button13
Autodials your voice messaging system (varies by system).Messages button14
Phone handset.
Cisco IP Phone 7811 supports both narrowband and wideband
handsets. Both the handset produces a magnetic field that attracts
small metallic objects such as pins and staples. To avoid possible
injuries do not keep small metallic objects close to the handset.
Note
Handset15
Cisco IP Phone 7811, 7821, 7841, and 7861 User Guide for Cisco Unified Communications Manager 10.0 (SIP)
4
Getting Started
Buttons and Hardware

Cisco 7811 Specifications

General

Wall Mountable	Yes
Protocols	SIP
Ethernet Switch	10/100
PoE	Yes, IEEE 802.3af (Class 1)
Handset	Standard Handset
Speakerphone	Yes
Headset Port	No
Codecs	G.722, iLBC
