QUICK REFERENCE Cisco Unified IP Phone User Guide for Cisco Unified Communications Manager 8.6 (SCCP and SIP) For Cisco Unified IP Phone 7962G, 7942G, 7961G, 7961G-GE, 7941G, and 7941G-GE Softkey Definitions Phone Screen Icons Button Icons Common Phone Tasks
Softkey Definitions
AbbrDial Dial using a speed-dial index
number
Answer Answers a call Back Returns to previous Help topic Barge Adds you to a call on a shared
line
CallBack Receive notification when a busy
extension becomes available
Cancel Cancels an action or exit a screen
without applying changes
cBarge Adds you to a call on a shared
line and establish a conference
CFwdALL Sets up/cancels call forwarding Clear Deletes records or settings Close Closes the current window ConfList View conference participants Confrn Creates a conference call Delete Removes characters to the right
of the cursor when using EditDial
Details Opens the Details record for a
multiparty call in the Missed Calls and Received Calls logs
Dial Dials a phone number DND Turns on/off Do Not Disturb
(DND)
EditDial Edits a number in a call log EndCall Disconnects the current call or
the current intercom call
Erase Resets settings to their defaults Exit Returns to the previous screen GPickUp Answers a call that is ringing in
another group or on another line
Common Phone Tasks
View online help on the phone
Press .
Place a call Lift the handset or press
the speakerphone or headset.
Redial a number Press Redial. Or press
the Navigation button while on hook to see your Placed Calls log.
Switch to the handset during a call
Pick up the handset.
Switch to the speaker or headset during a call
Press or , then hang up the handset.
Mute your phone Press . Use your call logs Press to choose a
call log. To dial, highlight a listing and go off hook.
Edit a number Press EditDial, << or >>. Hold/resume a call Press Hold or Resume.
Transfer a call to a new number
Press Transfer, enter the number, and then press Transfer again.
Place an intercom call Press intercom button,
enter a number if necessary, and speak after you hear the tone.
Start a standard (ad hoc) conference call
Press more > Confrn, dial the participant, then press Confrn again.
?

Cisco 7962G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Case material	ABS
Product color	Black, Grey
Wall mountable	Yes
Bluetooth	No
Security algorithms	128-bit AES, 802.1x RADIUS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.711, G.711a, G.722, G.729A, G.729ab, iLBC
Volume control	Digital
Display diagonal	5 \
Display resolution	320 x 222 pixels
Display number of colors	Monochrome
Caller ID	-
Lines quantity	- lines
Phonebook capacity	- entries
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	203.2 mm
Width	266.7 mm
Height	152.4 mm
Weight	1600 g
