Cisco 7962G User Manual

14 OL-22333-01
Set up, view, or
change WebDialer
preferences
Access the Make Call page. After you click the number that you want to dial,
the page appears the first time you use WebDialer and contains these options:
• Preferred language—Determines the language used for WebDialer
settings and prompts.
• Use preferred device—Identifies the Cisco Unified IP Phone (calling
device) and directory number (calling line) that you will use to place
WebDialer calls:
– If you have one phone with a single line, the appropriate phone and
line are selected automatically, or you can choose a phone
and/or line.
– If you have more than one phone, it will be specified by device type
and MAC address.
(To display the host name on the phone, choose > Network
Configuration > Host Name.)
If you have an Extension Mobility profile, you can select your Extension
Mobility logged-in device from the calling device menu.
• Do not display call confirmation—If selected, prompts WebDialer to
suppress the Make Call page. This page appears by default after you click
a phone number in a WebDialer-enabled online directory.
If you want to... Then...

Cisco 7962G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Case material	ABS
Product color	Black, Grey
Wall mountable	Yes
Bluetooth	No
Security algorithms	128-bit AES, 802.1x RADIUS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.711, G.711a, G.722, G.729A, G.729ab, iLBC
Volume control	Digital
Display diagonal	5 \
Display resolution	320 x 222 pixels
Display number of colors	Monochrome
Caller ID	-
Lines quantity	- lines
Phonebook capacity	- entries
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	203.2 mm
Width	266.7 mm
Height	152.4 mm
Weight	1600 g
