4-11
Cisco Unified IP Phone 7965G and 7945G Administration Guide for Cisco Unified Communications Manager 6.0
OL-12650-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
Related Topics
• Displaying a Configuration Menu, page 4-2
• Unlocking and Locking Options, page 4-3
• Editing Values, page 4-3
• Overview of Options Configurable from a Phone, page 4-4
• Device Configuration Menu, page 4-12
PC Port
Configuration
Speed and duplex of the access port (labeled
10/100/1000 PC). Valid values:
• Auto Negotiate
• 10 Half—10-BaseT/half duplex
• 10 Full—10-BaseT/full duplex
• 100 Half—100-BaseT/half duplex
• 100 Full—100-BaseT/full duplex
• 1000 Full—1000-BaseT/full duplex
If the phone is connected to a switch,
configure the port on the switch to the same
speed/duplex as the phone, or configure
both to auto-negotiate.
If you change the setting of this option, you
should change the SW Port Configuration
option to the same setting. This ensures that
the PC receives the full benefits of the
network operating speed.
1. Unlock network configuration
options.
2. Scroll to the PC Port
Configuration option and then
press the Edit softkey.
3. Scroll to the setting that you
want and then press the Select
softkey.
4. Press the Save softkey.
PC VLAN Allows the phone to interoperate with 3rd
party switches that do not support a voice
VLAN. The Admin VLAN ID option must
be set before you can change this option.
1. Unlock network configuration
options.
2. Make sure the Admin VLAN
ID option is set.
3. Scroll to the PC VLAN
option, press the Edit softkey,
and then enter a new PC
VLAN setting.
4. Press the Validate softkey and
then press the Save softkey.
Table 4-2 Network Configuration Menu Options (continued)
Option Description To Change
