Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
3 GE LAN 0
GE LAN 1
GE LAN 2
GE LAN 3
Green/Yellow Off—No link.
Green On—Link.
Yellow On—Fault with PoE. Implies no link.
Green Blinking—Data is either being received or
transmitted.
4 GE LAN 4
GE LAN 5
GE LAN 6
GE LAN 7
Green Off—No link.
On—Link.
Blinking—Data is either being received or being
transmitted.
5 GE WAN 8 Green Off—No link.
On—Link.
Blinking—Data is either being received or being
transmitted.
SFP WAN 8 Green Off—No link.
On—Link.
Blinking—Data is either being received or being
transmitted.
6 VPN Green Off—No tunnel.
On—At least one tunnel is up.
7 PPP Green Off—No PPP session.
On—At least one PPP session established.
8 xDSL CD0 Green Off—Interface is shutdown.
On—Showtime, Link up.
Slow Blinking—Modem initialization.
Fast Blinking—Training up the line.
If both CD0 & CD1 are ON then VDSL Bonding is
active.
xDSL CD1
xDSL DATA Green Off—No Data.
Blinking—Data is either being received or transmitted.
9 ISDN B1 Green Blinking—Data is either being received or transmitted.
Off—No Data.
ISDN B2
Table 1-39 LED Descriptions for the Cisco 897VAB-K9 ISR (continued)
Number LED Color Description

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
