Cisco 860 Series User Manual

1-9
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 810 Series
Figure 1-4 PoE+ Splitter I/O Side
SKU Information
Table 1-3 lists the different SKUs available for the Cisco 812 ISR. The AP802-AGN-X-K9 (WLAN PID)
is integrated as part of the router for the SKUs that support WLAN and is not orderable separately.
OUTPUT
OUTPUT
65 521
3 4
345067
1 Grounding location 4 PoE+ input
2 Power status LED 5 Openings for power cord latch to lock into
enclosure
3 GE0 output 6 Input power connection
Table 1-3 Supported SKUs
SKU ID WLAN PID Description
C812G+7-K9 — C812 Secure Router Standalone Unit (non-US) 3.7G HSPA
+ Release 7 with SMS/GPS
WLAN is not supported.
C812G-CIFI+7-E-K9 AP802-AGN-E-K9 C812 Secure Router (non-US) 3.7G HSPA + Release 7 with
SMS/GPS and Dual WiFi Radio with ETSI
C812G-CIFI+7-N-K9 AP802-AGN-N-K9 C812 Secure Router (non-US) 3.7G HSPA + Release 7 with
SMS/GPS and Dual WiFi Radio with ANZ
C812G-CIFI-V-A-K9 AP802-AGN-A-K9 C812 Secure Router for Verizon EV-DO Rev A with
SMS/GPS and Dual WiFi Radio with FCC
C812G-CIFI-S-A-K9 AP802-AGN-A-K9 C812 Secure Router for Sprint EV-DO Rev A with
SMS/GPS and Dual WiFi Radio with FCC

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
