c) Remove one screw from the left side of the chassis and one screw from the right side of the chassis.
Figure 50: Cisco ASR 1002-HX RouterTop Cover Screw Locations
d) Using both hands, gently slide the cover slightly backward and lift it off of the chassis.
Step 3
Position the chassis so that you have the most comfortable access to the chassis to remove the fans.
The fans are located at the rear of the chassis.
Step 4
Unplug the four fan connectors from the motherboard.
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
137
Removing and Replacing FRUs
Removing the Fans from a Cisco ASR 1002-HX Router

Cisco ASR 1001-HX Specifications

General

Form Factor	1 RU
Rack Mountable	Yes
Redundant Power Supply	Optional
Operating Temperature	32 to 104°F (0 to 40°C)
Memory	16 GB
Power Supply	Internal AC or DC
Humidity	5% to 95% non-condensing
Ports	Built-in 8 x 1GE and 4 x 10GE (SFP+)
Maximum NAT sessions	Up to 4 million
