Cisco ASR 1001-HX User Manual

Chassis front rack-mount bracket3Cable-management bracket "RU" feature1
Cable-management bracket screw2
Figure 30: Attaching the Cable-Management Brackets to the Cisco ASR 1002-HX Router
Chassis front rack-mount bracket3Cable-management bracket "U" feature1
Cable-management bracket screw holes2
Step 3
Do one of the following as appropriate:
• Cisco ASR 1001-HX Router—Insert the cable management screw into the screw hole of the
cable-management bracket and into the chassis rack-mount bracket and tighten the screw using a Phillips
screwdriver.
• Cisco ASR 1002-HX Router—Insert one screw through the bottom screw hole of the cable-management
bracket and into the chassis rack-mount bracket and tighten the screw using a Phillips screwdriver. Insert
another screw through the top screw hole of the cable-management bracket and tighten the screw.
Step 4
Repeat Step 1 through Step 3 for the other side of the chassis.
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
63
Installing the Router
Attaching the Cable Management Bracket

Cisco ASR 1001-HX Specifications

General

Form Factor	1 RU
Rack Mountable	Yes
Redundant Power Supply	Optional
Operating Temperature	32 to 104°F (0 to 40°C)
Memory	16 GB
Power Supply	Internal AC or DC
Humidity	5% to 95% non-condensing
Ports	Built-in 8 x 1GE and 4 x 10GE (SFP+)
Maximum NAT sessions	Up to 4 million
