Cisco ASR 1001-HX User Manual

Serial Number and PID/VID Label Location
The following figures show the location of the serial number and the PID/VID label on the Cisco ASR 1001-HX
Router and Cisco ASR 1002-HX Router.
Figure 12: Cisco ASR 1001-HX Router Serial Number and PID/VID Label Location
PID/VID Label2Serial Number1
Figure 13: Cisco ASR 1002-HX Router Serial Number and PID/VID Label Location
PID/VID Label2Serial Number1
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
14
Overview
Serial Number and PID/VID Label Location

Cisco ASR 1001-HX Specifications

General

Form Factor	1 RU
Rack Mountable	Yes
Redundant Power Supply	Optional
Operating Temperature	32 to 104°F (0 to 40°C)
Memory	16 GB
Power Supply	Internal AC or DC
Humidity	5% to 95% non-condensing
Ports	Built-in 8 x 1GE and 4 x 10GE (SFP+)
Maximum NAT sessions	Up to 4 million
