Cisco ASR 1001-HX - Chassis Ground Connection

Figure 32: Attaching the Grounding Lug to the Ground Connector of the Cisco ASR 1001-HX Router
Ground connector on the chassis3Chassis ground lug1
Ground symbol4Grounding screws2
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
66
Installing the Router
Attaching a Chassis Ground Connection
