APPENDIX B
Port Signals and Pinouts
This appendix provides the port signals and pinout specifications.
•
Management Ethernet Port Signals and Pinouts, page 147
•
Console Port Signals and Pinouts, page 147
•
Auxiliary Port Signals and Pinouts, page 148
Management Ethernet Port Signals and Pinouts
The following table lists the Management Ethernet 10/100 RJ-45 port pinouts.
DescriptionDirectionSignalPin
T/R data +I/OTX/RX AData +1
T/R data -I/OTX/RX AData -2
T/R Data +I/OTX/RX BData +3
T/R Data + (Unused for 10/100)I/OTX/RX CData +4
T/R Data - (Unused for 10/100)I/OTX/RX CData -5
T/R Data -I/OTX/RX BData -6
T/R Data + (Unused for 10/100)I/OTX/RX DData +7
T/R Data - (Unused for 10/100)I/OTX/RX DData -8
Console Port Signals and Pinouts
The following table lists the pinouts of the RJ-45 console port.
Cisco ASR 1001-HX Router and Cisco ASR 1002-HX Router Hardware Installation Guide
147

Cisco ASR 1001-HX Specifications

General

Form Factor	1 RU
Rack Mountable	Yes
Redundant Power Supply	Optional
Operating Temperature	32 to 104°F (0 to 40°C)
Memory	16 GB
Power Supply	Internal AC or DC
Humidity	5% to 95% non-condensing
Ports	Built-in 8 x 1GE and 4 x 10GE (SFP+)
Maximum NAT sessions	Up to 4 million
