Cisco CATALYST 2960

2-499
Catalyst 2960 Switch Command Reference
78-16882-01
Chapter 2 Catalyst 2960 Switch Cisco IOS Commands
test cable-diagnostics tdr
test cable-diagnostics tdr
Use the test cable-diagnostics tdr privileged EXEC command to run the Time Domain Reflector (TDR)
feature on an interface.
test cable-diagnostics tdr interface interface-id
Syntax Description
Defaults There is no default.
Command Modes Privileged EXEC
Command History
Usage Guidelines TDR is supported only on 10/100 and 10/100/1000 copper Ethernet ports. It is not supported on SFP
module ports. For more information about TDR, see the software configuration guide for this release.
After you run TDR by using the test cable-diagnostics tdr interface interface-id command, use the
show cable-diagnostics tdr interface interface-id privileged EXEC command to display the results.
Examples This example shows how to run TDR on an interface:
Switch# test cable-diagnostics tdr interface gigabitethernet0/2
TDR test started on interface Gi0/2
A TDR test can take a few seconds to run on an interface
Use 'show cable-diagnostics tdr' to read the TDR results.
If you enter the test cable-diagnostics tdr interface interface-id command on an interface that has a
link status of up and a speed of 10 or 100 Mbps, these messages appear:
Switch# test cable-diagnostics tdr interface gigabitethernet0/3
TDR test on Gi0/9 will affect link state and traffic
TDR test started on interface Gi0/3
A TDR test can take a few seconds to run on an interface
Use 'show cable-diagnostics tdr' to read the TDR results.
Related Commands
interface-id Specify the interface on which to run TDR.
Release Modification
12.2(25)FX This command was introduced.
Command Description
show cable-diagnostics tdr Displays the TDR results.
