Cisco Catalyst 3560-CX User Manual

System LED
System StatusColor
System is not powered on.Off
System is operating normally.Green
System is receiving power but is not operating
properly.
Amber
Modes for Port LEDs
The port LEDs, as a group or individually, display information about the switch and about the individual
ports.
DescriptionPort ModeLED
The port status. This is the default mode.Port statusSTAT
The port operating speed: 10, 100, or 1000
Mb/s.
Port speedSPEED
The PoE status.PoE port powerPoE
PoE LED
Even if the PoE mode is not selected, the LED shows PoE problems when they are detected. The PoE LED
is only on the switches that support PoE.
DescriptionColor
PoE is not enabled.Off
PoE is enabled. Ports are functioning correctly.Green
•
PoE mode is not selected
•
At least one of the 10/100 or 10/100/100 PoE ports has been denied
power
•
At least one of the ports has a PoE fault
Blinking amber
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
7
Product Overview
LEDs

Cisco Catalyst 3560-CX Specifications

General

Model	WS-C3560CX-8PC-S
Switching Capacity	20 Gbps
Product Type	Switch
Manageable	Yes
Layer Supported	Layer 3
Jumbo Frame Support	Yes
Jumbo Frame Size	9198 bytes
Input Voltage	100 - 240 VAC
Operating Temperature	32 to 113°F (0 to 45°C)
Power Supply	Internal
Ports	8 x 10/100/1000 Ethernet Ports
Uplink Ports	2 x 1G SFP
PoE	PoE+
Form Factor	Desktop, Wall-mountable
MAC Address Table Size	16, 000 entries
Power Source	AC
