Cisco Catalyst 3560-CX User Manual

Step 6
Secure the AC power cord by pressing on the retainer.
Figure 34: Securing the Power Cord in the Retainer
Installing the Cable Guard (Optional)
The cable guard prevents tampering with the cables after the cables are installed. The cable guard
(CMPCT-CBLE-GRD=) is not included with the switch, but you can order it from your Cisco representative.
You can use the cable guard when the switch is mounted on a desk, under a desk, or on a wall.Note
The cable guard is shipped with these items:
•
Two 0.5 in. (12.7 mm) number-8 Phillips wood screws
•
Two number-10 Phillips pan-head screws
•
Two washers
Step 1
(Optional) Attach the supplied washers before you install the cable guard.
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
39
Switch Installation
Installing the Cable Guard (Optional)

Cisco Catalyst 3560-CX Specifications

General

Model	WS-C3560CX-8PC-S
Switching Capacity	20 Gbps
Product Type	Switch
Manageable	Yes
Layer Supported	Layer 3
Jumbo Frame Support	Yes
Jumbo Frame Size	9198 bytes
Input Voltage	100 - 240 VAC
Operating Temperature	32 to 113°F (0 to 45°C)
Power Supply	Internal
Ports	8 x 10/100/1000 Ethernet Ports
Uplink Ports	2 x 1G SFP
PoE	PoE+
Form Factor	Desktop, Wall-mountable
MAC Address Table Size	16, 000 entries
Power Source	AC
