Step 4
Slide the retainer through the other latches to lock it.
Figure 32: Locking the Retainer
Latches3AC power cord1
Smaller sleeve for thin power cords2
Step 5
(Optional) Use the small sleeve for thin power cords. Use the small sleeve to provide greater stability for thin cords.
Detach the sleeve, and slide it over the power cord.
Figure 33: Sleeve Around the Power Cord
AC power cord2Smaller sleeve for thin power cords1
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
38
Switch Installation
Installing the Power Cord Retainer (Optional)

Cisco Catalyst 3560-CX Specifications

General

Model	WS-C3560CX-8PC-S
Switching Capacity	20 Gbps
Product Type	Switch
Manageable	Yes
Layer Supported	Layer 3
Jumbo Frame Support	Yes
Jumbo Frame Size	9198 bytes
Input Voltage	100 - 240 VAC
Operating Temperature	32 to 113°F (0 to 45°C)
Power Supply	Internal
Ports	8 x 10/100/1000 Ethernet Ports
Uplink Ports	2 x 1G SFP
PoE	PoE+
Form Factor	Desktop, Wall-mountable
MAC Address Table Size	16, 000 entries
Power Source	AC
