Cisco Catalyst 3560-CX User Manual

CONTENTS
Preface Preface vii
Document Conventions vii
Related Documentation ix
Obtaining Documentation and Submitting a Service Request ix
CHAPTER 1 Product Overview 1
Switch Models 1
Front Panel 2
PoE and PoE+ Ports 4
10/100/1000 Ports 4
Multigigabit ports 4
Management Ports 5
SFP and SFP+ Module Slots 6
LEDs 6
System LED 7
Modes for Port LEDs 7
PoE LED 7
Console LEDs 8
Port LEDs 8
Rear Panel 9
Internal Power Supply 10
Security Slot 10
Auxiliary Power Adapter 10
Management Options 11
Network Configurations 12
CHAPTER 2 Switch Installation 13
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
iii

Cisco Catalyst 3560-CX Specifications

General

Model	WS-C3560CX-8PC-S
Switching Capacity	20 Gbps
Product Type	Switch
Manageable	Yes
Layer Supported	Layer 3
Jumbo Frame Support	Yes
Jumbo Frame Size	9198 bytes
Input Voltage	100 - 240 VAC
Operating Temperature	32 to 113°F (0 to 45°C)
Power Supply	Internal
Ports	8 x 10/100/1000 Ethernet Ports
Uplink Ports	2 x 1G SFP
PoE	PoE+
Form Factor	Desktop, Wall-mountable
MAC Address Table Size	16, 000 entries
Power Source	AC
