If auto-MDIX is disabled, use the guidelines in this table to select the correct cable.
Table 2: Recommended Ethernet Cables (When Auto-MDIX is Disabled)
Straight-Through CableCrossover Cable
6
Device
NoYesSwitch to switch
NoYesSwitch to hub
YesNoSwitch to computer or server
YesNoSwitch to router
YesNoSwitch to IP phone
6
100BASE-TX and 1000BASE-T traffic requires twisted four-pair, Category 5, Category 5e, or Category 6 cable. 10BASE-T traffic can use Category 3 or
Category 4 cable.
Where to Go Next
If the default configuration is satisfactory, the switch does not need further configuration. You can use any
of these management options to change the default configuration:
•
Start the Network Assistant application, which is described in the getting started guide. Through this
GUI, you can configure and monitor a switch cluster or an individual switch.
•
Use the CLI to configure the switch as a member of a cluster or as an individual switch from the console.
•
Use the Cisco Prime Infrastructure application.
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
47
Switch Installation
Where to Go Next

Cisco Catalyst 3560-CX Specifications

General

Model	WS-C3560CX-8PC-S
Switching Capacity	20 Gbps
Product Type	Switch
Manageable	Yes
Layer Supported	Layer 3
Jumbo Frame Support	Yes
Jumbo Frame Size	9198 bytes
Input Voltage	100 - 240 VAC
Operating Temperature	32 to 113°F (0 to 45°C)
Power Supply	Internal
Ports	8 x 10/100/1000 Ethernet Ports
Uplink Ports	2 x 1G SFP
PoE	PoE+
Form Factor	Desktop, Wall-mountable
MAC Address Table Size	16, 000 entries
Power Source	AC
