To prevent airflow restriction, allow clearance around the ventilation openings to be at least: 3 in. (7.6 cm)
Statement 1076
Figure 23: Mounting the Switch in a Rack
On a DIN Rail
The DIN-mount kit (part number CMPCT-DIN-MNT=) is optional. You can order it when you order your
switch, or you can order it later from your Cisco representative.
The DIN-mount kit contains:
Two number-10 Phillips pan-head screws
DIN rail mount
To install the switch on a DIN rail, follow the instructions described in these sections:
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
30
Switch Installation
On a DIN Rail
