Cisco Catalyst 3560-CX User Manual

Step 2
Slide the retainer around the AC power cord, and pass it around the loop on the switch.
Figure 30: Inserting the Retainer through the Lanced Loop
Sleeve for thinner power cords3AC power cord1
Loop4Power cord retainer2
Step 3
Slide the retainer through the first latch.
Figure 31: Sliding the Retainer Through the Latch
Latch3AC power cord1
Smaller sleeve for thin power cords2
Catalyst 3560-CX and 2960-CX Switch Hardware Installation Guide
37
Switch Installation
Installing the Power Cord Retainer (Optional)

Cisco Catalyst 3560-CX Specifications

General

Model	WS-C3560CX-8PC-S
Switching Capacity	20 Gbps
Product Type	Switch
Manageable	Yes
Layer Supported	Layer 3
Jumbo Frame Support	Yes
Jumbo Frame Size	9198 bytes
Input Voltage	100 - 240 VAC
Operating Temperature	32 to 113°F (0 to 45°C)
Power Supply	Internal
Ports	8 x 10/100/1000 Ethernet Ports
Uplink Ports	2 x 1G SFP
PoE	PoE+
Form Factor	Desktop, Wall-mountable
MAC Address Table Size	16, 000 entries
Power Source	AC
