7-10
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
Appendix 7 Connector and Cable Specifications
Cable and Adapter Specifications
want to connect the switch console port to a terminal. You can order a kit with an adapter (part
number ACS-DSBUASYN=). For console port and adapter pinout information, see Table 7-2 and
Table 7-3.
Table 7-2 lists the pinouts for the console port, the RF-45-to-DB-9 adapter cable, and the console device.
Table 7-3 lists the pinouts for the console port, RJ-45-to-DB-25 female DTE adapter, and the
console device.
Note The RJ-45-to-DB-25 female DTE adapter is not supplied with the switch. You can order a kit with the
adapter (part number ACS-DSBUASYN=) from Cisco.
Table 7-2 Console Port Signaling Using a DB-9 Adapter
Switch Console
Port (DTE)
RJ-45-to-DB-9
Terminal Adapter
Console
Device
Signal DB-9 Pin Signal
RTS 8 CTS
DTR 6 DSR
TxD 2 RxD
GND 5 GND
GND 5 GND
RxD 3 TxD
DSR 4 DTR
CTS 7 RTS
Table 7-3 Console Port Signaling Using a DB-25 Adapter
Switch Console
Port (DTE)
RJ-45-to-DB-25
Terminal Adapter
Console
Device
Signal DB-25 Pin Signal
RTS 5 CTS
DTR 6 DSR
TxD 3 RxD
GND 7 GND
GND 7 GND
RxD 2 TxD
DSR 20 DTR
CTS 4 RTS
