CHAPTER

3-1

Catalyst 3650 Switch Hardware Installation Guide

OL-29734-01

Power Supply Installation

This chapter describes how to install the power supply modules.

• Power Supply Module Overview, page 3-1

• Installation Guidelines, page 3-7

• Installing or Replacing an AC Power Supply, page 3-8

• Installing a DC Power Supply, page 3-9

• Finding the Power Supply Module Serial Number, page 3-14

Note This chapter does not apply to Catalyst 3650-24PDM and 3650-48FQM switches. These switches come

with fixed power supply modules and require no separate installation.

Power Supply Module Overview

The switch operates with either one or two active power supply modules.

You can use two AC modules, two DC modules, one AC and one DC module, or one module and a blank

cover.

Note In a NEBS installation, you can use two DC modules or one DC module and a blank cover.

All switches ship with a blank cover in the second power supply slot if switches are configured with only

one power supply.

Table 3-1 describes the supported internal power supply modules.

Table 3-1 Power Supply Module Part Numbers and Descriptions

Part Number Description

PWR-C1-1100WAC 1100-W AC power supply module

PWR-C1-715WAC 715-W AC power supply module

PWR-C1-440WDC 440-W DC power supply module

PWR-C1-BLANK Blank cover

PWR-C2-1025WAC 1025-W AC power supply module
