APPENDIX B
Connector and Cable Specifications
Connector Specifications, on page 121
Console Port, on page 123
Cables and Adapters, on page 123
Connector Specifications
10/100/1000 Ports (Including PoE)
All 10/100/1000 ports use standard RJ-45 connectors and Ethernet pinouts.
Figure 67: 10/100/1000 Port Pinouts
Module Connectors
Figure 68: Duplex LC Cable Connector
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
121
