Cisco Catalyst 9300 Series Hardware Installation Guide

Mounting the Switch in a Rack
Procedure
Step 1 Use the four supplied Phillips machine screws to attach the brackets to the rack.
Step 2 Use the black Phillips machine screw to attach the cable guide to the left or right bracket.
Figure 32: Front-Mounting Position
Number-12 or number-10 Phillips machine
screws
3Phillips machine screw, black1
--Cable guide2
Figure 33: Mid-Mounting Position
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
58
Installing a Switch
Mounting the Switch in a Rack

Cisco Catalyst 9300 Series Specifications

General

Operating System	Cisco IOS XE
Model	Cisco Catalyst 9300 Series
Uplink Interfaces	10G, 25G, 40G
Downlink Interfaces	1G
Stacking Bandwidth	480 Gbps
Power Supply	Redundant power supplies
PoE	UPOE
Port Density	Up to 48 ports
Power over Ethernet (PoE)	UPOE, UPOE+
Security Features	MACsec
Management	Cisco DNA Center, CLI, SNMP
Redundancy	Stacking, redundant power supplies, hot-swappable fans
