Cisco Catalyst 9300 Series Hardware Installation Guide

CHAPTER 5
Installing a Power Supply
• Power Supply Modules Overview, on page 81
• Installation Guidelines, on page 86
• Installing or Replacing an AC Power Supply, on page 87
• Installing a DC Power Supply, on page 89
• Finding the Power Supply Module Serial Number, on page 94
Power Supply Modules Overview
The switch operates with either one or two active power supply modules. A switch that is part of a StackPower
stack operates with power that is supplied by other stack switches.
You can use two AC modules or one module and blank cover. All power supply modules have internal fans.
All switches ship with a blank cover in the second power supply slot.
The following table describes the supported internal power supply modules. It lists the Platinum certified
power supply modules and the default modules that are shipped with the switch. In a switch, a mix of Platinum
certified and non-Platinum certified power supply modules is supported.
Table 32: Power Supply Module Part Numbers and Descriptions
DescriptionSupported Power Supply ModulesSwitch Series
350 W AC power supply modulePWR-C1-350WACC9300 Series
Switches
715 W AC power supply modulePWR-C1-715WAC
1100 W AC power supply modulePWR-C1-1100WAC
715 W AC Platinum certified power supply
module
PWR-C1-715WAC-P
1100 W AC Platinum certified power supply
module
PWR-C1-1100WAC-P
1900 W AC Platinum certified power supply
module
PWR-C1-1900WAC-P
715 W DC power supply modulePWR-C1-715WDC
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
81

Cisco Catalyst 9300 Series Specifications

General

Operating System	Cisco IOS XE
Model	Cisco Catalyst 9300 Series
Uplink Interfaces	10G, 25G, 40G
Downlink Interfaces	1G
Stacking Bandwidth	480 Gbps
Power Supply	Redundant power supplies
PoE	UPOE
Port Density	Up to 48 ports
Power over Ethernet (PoE)	UPOE, UPOE+
Security Features	MACsec
Management	Cisco DNA Center, CLI, SNMP
Redundancy	Stacking, redundant power supplies, hot-swappable fans
