Figure 10: Rear Panel of a Cisco Catalyst 9300 Series Switch
StackPower connectors7Ground connectors1
AC OK (input) status LED8USB3.0–SSD port2
PS OK (output) status LED9BEACON LED3
StackWise-480 port connectors10CONSOLE (RJ-45 console port)4
Power supply modules11MGMT (RJ-45 10/100/1000 management
port)
5
--Fan modules6
