Cisco Catalyst 9300 Series Hardware Installation Guide

Figure 36: Inserting the StackWise-320 Adapter
StackWise port2StackWise-320 adapter1
Step 4 Align and insert the StackWise cable connector into the StackWise adapter in the StackWise port. Push inwards
until the spring latch locks into the slot.
Figure 37: Installing the StackWise-320 Cable in a StackWise Port
Stacking cable2StackWise-320 adapter1
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
61
Installing a Switch
Connecting a StackWise-320 Cable

Cisco Catalyst 9300 Series Specifications

General

Operating System	Cisco IOS XE
Model	Cisco Catalyst 9300 Series
Uplink Interfaces	10G, 25G, 40G
Downlink Interfaces	1G
Stacking Bandwidth	480 Gbps
Power Supply	Redundant power supplies
PoE	UPOE
Port Density	Up to 48 ports
Power over Ethernet (PoE)	UPOE, UPOE+
Security Features	MACsec
Management	Cisco DNA Center, CLI, SNMP
Redundancy	Stacking, redundant power supplies, hot-swappable fans
