IP Settings
To set up the switch, you need to assign an IP address and other configuration information necessary for the
switch to communicate with the local routers and the Internet.
You will need this information from your network administrator:
• Switch IP address
• Subnet mask (IP netmask)
• Default gateway (router)
• TFTP Server
Performing the Initial Configuration
The bootup script runs the configuration wizard, which prompts you for basic configuration input. At any
point you may enter a question mark '?' for help. Use Ctrl+C to abort the configuration dialog at any prompt.
Default settings are in square brackets '[ ]'.
Procedure
Step 1 Respond to whether you would like to enter the initial configuration dialog
Example:
Would you like to enter the initial configuration dialog? [yes/no]: yes
Step 2 Repond to whether you would like to enter basic management setup
Example:
Would you like to enter basic management setup? [yes/no]: yes
Step 3 Repond to whether you would like to enter basic management setup
Example:
Would you like to enter basic management setup? [yes/no]: yes
Configuring global parameters:
Enter host name [Switch]: Switch
The enable secret is a password used to protect access to
privileged EXEC and configuration modes. This password, after
entered, becomes encrypted in the configuration.
Enter enable secret: examplesecret
The enable password is used when you do not specify an
enable secret password, with some older software versions, and
some boot images.
Enter enable password: exampleenable
The virtual terminal password is used to protect
access to the router over a network interface.
Enter virtual terminal password: examplevtp
Setup account for accessing HTTP server? [yes]: yes
Username [admin]:
Password [cisco]:
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
154
Initial Configuration for the Switch
IP Settings
