Cisco Catalyst 9404R Switch User Manual

Figure 12: Chassis handholds
--All four of the chassis handholds pulled out
and the back end of the chassis resting on the
edges of the shelf bracket rails.
1
Step 2 With a person standing at each side of the chassis, insert one hand into each handhold. Slowly lift the chassis.
Avoid sudden twists or moves to prevent injury.
Step 3 Rest the back end of the chassis on the edges of the shelf bracket rails and slide it in until the first pair of
handles on both sides of the chassis are near the rack posts.
Step 4 Push in the handholds that are closest to the rack posts
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
56
Installing the Switch
Rack-Mounting the Chassis
