Figure 14: Sliding the Chassis in - Part 2
--Chassis is slid in until the second pair of
handholds are near the rack posts.
1
Step 6 Push in the the second pair of handholds and continue sliding the chassis in until the L brackets make contact
with the rack posts.
Step 7 Secure the chassis to the rack with either the 10-32 or 12-24 pan head screws from the chassis standard
accessory kit.
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
58
Installing the Switch
Rack-Mounting the Chassis
