Cisco Catalyst 9404R Switch

Remaining screws that are mounted when
installing the cable guide—one on each side
for the shelf bracket and two on each side
for the L bracket.
2Screws that are mounted before the cable
guide is—two on each side for the shelf
bracket and one on each side for the L
bracket.
1
Cable guide installation with shelf brackets is complete.
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
63
Installing the Switch
Installing the Cable Guide With Shelf Brackets
