--Power supply in the OFF (0) position1
Step 2 Loosen and remove the retainer strip that is around the power cord.
See Power Cord Retainer Mechanism, on page 98
Step 3 Remove the power cord from AC-in receptacle.
Step 4 Press the release latch at the right side of the power supply module inward.
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
93
Removing and Replacing FRUs
Removing the Power Supply
