Cisco Content Delivery Engine 205/220/250/280/285/420/460/475 Hardware Installation Guide
Chapter 1 Overview of the Content Delivery Engines
Hardware Features
CDE250 2M0
Figure 1-27 is a front view of the CDE250 2M0 showing the location of the storage drives. Table 1-32
lists the CDE250 2M0 PCI expansion cards and their corresponding PCI slot numbers (see Figure 1-9 to
see the location of the PCI expansion slots).
Figure 1-27 CDE250 2M0 Drives
CDE250 2S5
Figure 1-28 is a front view of the CDE250 2S5 showing the location of the storage drives. Table 1-33
lists the CDE250 2S5 PCI expansion cards and their corresponding PCI slot numbers (see Figure 1-9 to
see the location of the PCI expansion slots).
Note If this CDE is in an IS system, the storage drive numbering is from 0 to 25.
Figure 1-28 CDE250 2S5 Drives
RESET
285399
1
2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
Table 1-32 CDE250 2M0 PCI Expansion Cards
PCI Expansion
Slot Number
Expansion Card Interface Name
(top to bottom)
1— —
2 NIC—dual (10GE) fiber 1/0 2/0
3— —
4— —
5— —
6 NIC—dual (10GE) fiber 3/0 4/0
7 NIC—quad copper 3/0 4/0 5/0 6/0
RESET
2
54338
1
2 3 4 5 6 7 8
9 10 11 12
