Figure 2: Firepower 9300 Package Contents
Blue console cable PC terminal adapter2Firepower 9300 chassis1
Two rack static rails
Adjusts to fit racks with a 24 in. to 36 in.
front-to-rear rail span
4Two power cords (country specific)3
Four 10-32 retention nuts for rack-mounting6Four 10-32 x .5 in. screws used to attach the rails
to rack
5
10/100/1000BASE-T SFP transceiver8Four 10-32 x .75 in. Philips head screws used to
attach the chassis to the rack
7
Two 10-32 x .375 in. screws used to attach the
ground lug
10One ground lug #6 AWG, 90 degree, #10 post
The ground lug ships with the DC
power version of the Firepower 9300.
Note
9
Cisco Firepower 9300
This document has a URL pointing to the
hardware installation guide, a URL pointing the
regulatory and safety guide, and a QR code and
URL pointing to the Getting Started Guide.
11
Cisco Firepower 9300 Hardware Installation Guide
7
Overview
Package Contents
