Security module 12Security module 31
1 Gigabit Ethernet management port4RJ-45 console port3
Eight 10 Gigabit Ethernet data ports (Gigabit
Ethernet 1/1 through 1/8)
62.0 USB port5
Network module 18Supervisor7
Security module 210Network module 29
Power supply module PSU-112Power supply module PSU-211
For More Information
See Chassis Components, on page 4 for a list of all of the chassis components.
See Supervisor, on page 11 for detailed information about the Supervisor.
See Security Modules, on page 13 for detailed information about the security modules.
See Network Modules, on page 15 for detailed information about the network modules.
See Hardware Bypass Network Modules, on page 21 for detailed information about hardware bypass
network modules
See Power Supply Modules, on page 26 for detailed information about the power supply modules.
Rear Panel
The following figure shows the rear panel of the Firepower 9300.
Figure 6: Firepower 9300 Rear Panel
Power feed for PSU-12Power feed for PSU-21
Fan module FAN-14On/Off switch3
Cisco Firepower 9300 Hardware Installation Guide
10
Overview
Rear Panel
