Page #76 background imageLoading...
Page #76 background image
Connect the DC Power Supply Module
Statement 1002DC Power Supply
When stranded wiring is required, use approved wiring terminations such as closed-loop or spade-type with
upturned lugs. These terminations should be the appropriate size for the wires and should clamp both the
insulation and conductor.
Warning
Statement 1074Comply with Local and National Electrical Codes
To reduce risk of electric shock or fire, installation of the equipment must comply with local and national
electrical codes.
Warning
Replace power supplies immediately. Power supply blanks are not available.
Note
This procedure describes how to install and connect the DC power supply module to the rear PDU terminals
on the chassis.
Before you begin
You need the following to connect the DC power supply module:
Phillips head screwdriver
10-mm wrench or socket
Connectors and wire for the DC circuit or circuits
Two 2-hole lugs
These lugs are not provided in the accessory kit. We recommend lugs similar to the 90-degree DC Burndy
YAZ6C2TC1490 lug. It accepts ¼-20 threaded studs and has the correct stud spacing.
Step 1 Install the DC power supply module in the chassis and make note of the bay number so you can connect the wiring to
the correct terminals on the DC power supply module at the rear of the chassis. See Remove and Replace the Power
Supply Module, on page 70 for the procedure.
Step 2 Verify that the power is off to the DC circuit on the power supply module that you are installing.
Step 3 Make sure that all site power and grounding requirements have been met.
Step 4 Remove the plastic cover from the DC terminals by squeezing the flanges at the top and bottom of the cover.
Step 5 Using the screws, connect the green ground wires to the chassis ground terminal.
Only one ground connection is required even though there may be up to 2 DC connections.
Step 6 Using the screws, connect the two 2-hole lugs to the power supply module terminal block.
Cisco Firepower 9300 Hardware Installation Guide
72
Installation, Maintenance, and Upgrade
Connect the DC Power Supply Module
