Cisco Firepower 9300 - 10-Gb Network Module

• See 40-Gb Network Module, on page 17 for a description of the 40-Gb network module.
• See 100-Gb Network Module (Two Ports, Single Wide), on page 19 for a description of the 100-Gb
two-port single-wide network module.
• See 100-Gb Network Module (Four Ports, Single Wide), on page 20 for a description of the 100-Gb
four-port single-wide network module
• See 100-Gb Network Module (Double Wide), on page 21 for a description of the 100-Gb double-wide
network module.
• See Supported SFP/SFP+ and QSFP Transceivers, on page 28 for a list of supported SFPs.
• See Install, Remove, and Replace the Single-Wide Network Module, on page 63 for the procedure
for removing and replacing single-wide network modules.
• See Install, Remove, and Replace the Double-Wide Network Module, on page 67 for the procedure
for removing and replacing double-wide network modules.
10-Gb Network Module
The following figure shows the front panel of the 10-Gb network module (FPR9K-NM-8X10G). The
FPR9K-NM-8X10G is a single-wide module that supports hot swapping. The eight ports are numbered from
top to bottom, left to right.
Make sure you have the correct firmware package and software version installed to support this network
module. For instructions on how to verify your firmware package version and to upgrade the firmware if
necessary, see the Cisco Firepower 4100/9300 FXOS Firmware Upgrade Guide. See Cisco Firepower 4100/9300
FXOS Compatibility for the software compatibility matrix.
Note
The FPR9K-NM-8X10G is NEBS-compliant.
Note
You can fit four copper SFPs in either the top row of ports or the bottom row of ports. Both rows cannot be
populated at the same time, because of the port row spacing.
Note
