Cisco IP Communicator Administration Guide

Chapter 7 Viewing Operational Information
Viewing Operational Information Locally on the Cisco IP Communicator Interface
7-4
Cisco IP Communicator Administration Guide for Cisco CallManager
OL-4698-01
Table 7-2 Device Configuration items displayed on Cisco IP Communicator
Option Description
Call Manager 1
Call Manager 2
Call Manager 3
Call Manager 4
Call Manager 5
Cisco CallManager servers that are available for processing calls from this
application, in prioritized order. For an available server, an option will show the
Cisco CallManager server IP address and one of the following states:
• Active—Cisco CallManager server from which the application is currently
receiving call-processing services.
• Standby—Cisco CallManager server to which the application switches if the
current server becomes unavailable.
• Blank—No current connection to this Cisco CallManager server.
An option may also include the Survivable Remote Site Telephony (SRST)
designation, which indicates an SRST router capable of providing Cisco
CallManager functionality with a limited feature set. This router assumes control
of call processing if all other Cisco CallManager servers become unreachable. The
SRST Cisco CallManager always appears last in the list of servers, even if it is
active. You configure the SRST router address in the Device Pool section in
Cisco CallManager.
Directories URL URL of the server from which the application obtains directory information.
Services URL URL of the server from which the application obtains Cisco IP Phone services.
Messages URL URL of the server from which the application obtains message services.
Information URL URL of the help text that appears on the application.
Authentication
URL
URL that the application uses to validate requests made to the application web
server.
Proxy Server
URL
URL used to proxy HTTP requests for access to non-local host addresses from the
application HTTP client.
Idle URL URL that the application displays when the application has not been used for the
time specified in the Idle URL Time option. For example, you could use the Idle
URL option and the Idle URL Timer option to display a log on the LCD screen
when the application has not been used for five minutes.
Idle URL Time Amount of time in seconds that elapses before the URL specified in the Idle URL
option appears.
