7-15
Cisco IP Communicator Administration Guide for Cisco CallManager
OL-4698-01
Chapter 7 Viewing Operational Information
Viewing Operational Information Remotely from a Web Page
Viewing Streaming Statistics Remotely
A Cisco IP Communicator device can stream information to and from up to three
devices simultaneously. Cisco IP Communicator streams information when it is
on a a call or running a service that sends or receives audio or data.
The streaming statistics areas on the device web page provide information about
the streams. Most calls use only one stream (Stream 1), but some calls use two or
three stream. For example, a barged call uses Stream 1 and Stream 2.
Table 7-8 describes the items in the Streaming Statistics areas.
To display a Streaming Statistics area, access the web page as described in the
“Accessing the Web Page for a Device” section on page 7-10, then click
Stream 1, Stream 2, or Stream 3.
Table 7-8 Streaming statistics displayed on the device web page
Item Description
Domain Domain of the device
Remote Address IP address of the destination of the stream
Local Address IP address of the device
Sender Joins Number of times the device has started transmitting a stream
Receiver Joins Number of times the device has started receiving a stream
Byes Number of times the device has stopped transmitting a stream
Start Time Internal time stamp indicating when Cisco CallManager requested that the
device start transmitting packets
Row Status Whether the device is streaming
Host Name Host name of the device
Sender Packets Total number of packets sent by the device
Sender Octets Total number of octets sent by the device
Sender Tool Type of audio encoding used for the stream
Sender Reports Number of times this streaming statistics report has been accessed from the
web page (resets when the device resets)
Sender Report Time Internal time stamp indicating when this streaming statistics report was
generated
