Cisco IP Communicator User Manual

14 OL-5051-01
Phone Screen Features
This is what your Cisco IP Communicator phone screen might look like with a call active and several
feature menus open. You can click screen items to select or activate them.
Related topics
• Using the Cisco IP Communicator Interface, page 10
• Call-Handling and Navigation Tips, page 15
1
Primary line Displays your primary extension number and the time and date. If several
tabs are open, the time and date alternate with the extension number.
2
Line area Displays your extension number(s). Each extension represents a phone line
and corresponds to a (line button).
3
Speed dial area Displays speed dial labels. Each label corresponds to a speed dial button.
See the “Setting Up Speed Dial Buttons” section on page 33.
4
Softkey labels Each displays a softkey function. Activate a softkey by clicking the softkey
label or the button below the label.
5
Status line Displays status information and user prompts.
6
Call activity area Displays currently active calls, including caller ID, call duration, and
call-state icons. You can click an active call to select it.
7
Phone tab Appears when there is call activity. Click this tab to return to the call
activity area from another screen.
8
Feature tabs Each indicates an open feature menu. Feature tabs appear after you open a
feature by clicking the corresponding feature button:
,,,, or .
