10-29
Cisco ONS 15454 SONET/SDH ML-Series Multilayer Ethernet Card Software Feature and Configuration Guide, R4.0
78-15224-02
Chapter 10 Configuring Networking Protocols
Configuring IP Routing
The following examples show various information about the BGP configuration:
Router# show ip protocols
Routing Protocol is "bgp 1"
Outgoing update filter list for all interfaces is not set
Incoming update filter list for all interfaces is not set
IGP synchronization is enabled
Automatic route summarization is enabled
Redistributing: connected
Neighbor(s):
Address FiltIn FiltOut DistIn DistOut Weight RouteMap
192.168.2.1
Maximum path: 1
Routing for Networks:
Routing Information Sources:
Gateway Distance Last Update
Distance: external 20 internal 200 local 200
Router# show ip bgp neighbor
BGP neighbor is 192.168.2.1, remote AS 1, internal link
BGP version 4, remote router ID 192.168.2.1
BGP state = Established, up for 00:08:46
Last read 00:00:45, hold time is 180, keepalive interval is 60 seconds
Neighbor capabilities:
Route refresh: advertised and received(new)
Address family IPv4 Unicast: advertised and received
Received 13 messages, 0 notifications, 0 in queue
Sent 13 messages, 0 notifications, 0 in queue
Route refresh request: received 0, sent 0
Default minimum time between advertisement runs is 5 seconds
For address family: IPv4 Unicast
BGP table version 3, neighbor version 3
Index 1, Offset 0, Mask 0x2
2 accepted prefixes consume 72 bytes
Prefix advertised 2, suppressed 0, withdrawn 0
Number of NLRIs in the update sent: max 2, min 0
Connections established 1; dropped 0
Last reset never
Connection state is ESTAB, I/O status: 1, unread input bytes: 0
Local host: 192.168.2.2, Local port: 179
Foreign host: 192.168.2.1, Foreign port: 11001
Enqueued packets for retransmit: 0, input: 0 mis-ordered: 0 (0 bytes)
Event Timers (current time is 0x45B7B4):
Timer Starts Wakeups Next
Retrans 13 0 0x0
TimeWait 0 0 0x0
Table 10-6 BGP Show Commands
Command Purpose
Router# show ip protocols [summary]
Displays the protocol configuration.
Router# show ip bgp neighbor
Displays detailed information about the BGP and TCP
connections to individual neighbors.
Router# show ip bgp summary
Displays the status of all BGP connections.
Router# show ip bgp
Displays the content of the BGP routing table.
