Chapter 1 Install the Shelf and Backplane Cable
NTP-A6 Install the Power and Ground
Warning A readily accessible two-poled disconnect device must be incorporated in the fixed wiring.
Warning When installing redundant power feeds, do not use aluminum conductors.
Warning If you use redundant power leads to power the ONS 15454, disconnecting one lead will not remove
power from the node.
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Step 1 Complete the “DLP-A15 Verify that the Correct Fuse and Alarm Panel is Installed in the Equipment
Rack” task on page 1-24.
Step 2 Complete the “DLP-A16 Connect the Office Ground to the ONS 15454” task on page 1-25.
Step 3 Complete the “DLP-A17 Connect Office Power to the ONS 15454 Shelf” task on page 1-26.
Step 4 Complete the “DLP-A18 Turn On and Verify Office Power” task on page 1-28.
Step 5 Continue with the “NTP-A7 Install the Fan-Tray Assembly” procedure on page 1-29.
Stop. You have completed this procedure.
DLP-A15 Verify that the Correct Fuse and Alarm Panel is Installed in the
Equipment Rack
Step 1 Verify the following:
• If using the 15454-SA-ANSI shelf, a 100-A fuse panel (30-A fuse per shelf minimum) is installed.
If not, install one according to manufacturer’s instructions.
• If using the 15454-SA-NEBS3 shelf, a standard 80-A fuse panel (20-A fuse per shelf minimum) is
installed. If not, install one according to manufacturer’s instructions.
Step 2 Return to your originating procedure (NTP).
Purpose This task verifies that the proper fuse and alarm panel is installed in the
equipment rack.
Tools/Equipment None
Prerequisite Procedures None
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
