Chapter 1 Install the Shelf and Backplane Cable
NTP-A2 Install the Shelf Assembly
Warning To prevent the equipment from overheating, do not operate it in an area that exceeds the maximum
recommended ambient temperature of 131°F (55°C). To prevent airflow restriction, allow at least
1 inch (25.4 mm) of clearance around the ventilation openings.
Warning The ONS 15454 should be installed in the lower rack position or mounted above another ONS 15454
shelf assembly.
Warning The ONS 15454 must have 1 inch of airspace below the installed shelf assembly to allow air flow to
the fan intake. The air ramp (the angled piece of sheet metal on top of the shelf assembly) provides
this spacing and should not be modified in any way.
Note The 10 Gbps compatible shelf assembly (15454-SA-10G) and fan-tray assembly (15454-FTA3) are
required with the ONS 15454 XC10G, OC-192, and OC-48 any slot (AS) cards.
Step 1 Complete the “DLP-A3 Reverse the Mounting Bracket to Fit a 19-inch (482.6 mm) Rack” task on
page 1-6 if you need to convert from a 23-inch (584.2 mm) to a 19-inch (482.6 mm) rack.
Step 2 To install the air filter in an alternative location, complete the “DLP-A4 Install the External Brackets and
Air Filter” task on page 1-8.
Step 3 Complete the necessary rack mount task:
• DLP-A5 Mount the Shelf Assembly in a Rack (One Person), page 1-9
• DLP-A6 Mount the Shelf Assembly in a Rack (Two People), page 1-10
• DLP-A7 Mount Multiple Shelf Assemblies in a Rack, page 1-11
Step 4 Continue with the “NTP-A3 Open and Remove the Front Door” procedure on page 1-12.
Stop. You have completed this procedure.
DLP-A3 Reverse the Mounting Bracket to Fit a 19-inch (482.6 mm) Rack
Purpose This task installs the mounting bracket to convert a 23-inch (584.2 mm)
rack to a 19-inch (482.6 mm) rack.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Prerequisite Procedures None
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
