1-42
Cisco ONS 15454 Procedure Guide, R4.0
March 2003
Chapter 1 Install the Shelf and Backplane Cable
NTP-A120 Install an External Wire-Wrap Panel to the AEP
12 ALARM_IN_15- 38 ALARM_IN_16-
13 ALARM_IN_17- 39 GND
14 GND 40 ALARM_IN_18-
15 ALARM_IN_19- 41 ALARM_IN_20-
16 ALARM_IN_21- 42 GND
17 GND 43 ALARM_IN_22-
18 ALARM_IN_23- 44 ALARM_IN_24-
19 ALARM_IN_25- 45 GND
20 GND 46 ALARM_IN_26-
21 ALARM_IN_27- 47 ALARM_IN_28-
22 ALARM_IN_29- 48 GND
23 GND 49 ALARM_IN_30-
24 ALARM_IN_31- 50 —
25 ALARM_IN_+ 51 GND1
26 ALARM_IN_0- 52 GND2
Table 1-6 Alarm Output Pin Assignments
AMP Champ Pin Signal Name AMP Champ Pin Signal Name
1— 27COM_0
2COM_128—
3 NO_1 29 NO_2
4— 30COM_2
5COM_331—
6 NO_3 32 NO_4
7— 33COM_4
8COM_534—
9 NO_5 35 NO_6
10 — 36 COM_6
11 COM_7 37 —
12 NO_7 38 NO_8
13 — 39 COM_8
14 COM_9 40 —
15 NO_9 41 NO_10
16 — 42 COM_10
17 COM_11 43 —
Table 1-5 Alarm Input Pin Assignments (continued)
AMP Champ Pin Signal Name AMP Champ Pin Signal Name
