Cisco SCE 8000 User Manual

8-6
Cisco SCE8000 GBE Installation and Configuration Guide
Chapter 8 Troubleshooting
Information About Troubleshooting Tools
Warning Cisco SCE 8000 is fully operational (as above) but one of the
following occurred:
• GBE Management port link is down.
• Internal temperature above threshold.
• Internal voltage not in expected range.
• Fan problem.
• Power supply problem.
• Insufficient space on the disk.
Note If the condition that caused the Cisco SCE 8000 to be in
Warning state is resolved (for example, link is up) the
Cisco SCE 8000 reverts to Operational state.
Flashing amber
Failure System is in Failure state after Boot because of one of the
following conditions:
• Power-on test failure.
• Three abnormal reboots in less than 30 minutes.
• Platform configured to enter Failure mode consequent to
failure-induced reboot (this is configurable using CLI
command).
• Severe system health problem, such as extensive overheating
or voltage out of correct operating range.
Note Depending on the cause of failure, the management
interface and the platform configuration may or may not be
active/available.
Red
Table 8-3 Power Supply LEDs
LED Label Color State Function
INPUT OK Green On Input voltage is present and within the required
range.
— — Off Input voltage is not present or not within the required
range.
OUTPUT FAIL Green On Output voltage is not within the required range.
— — Off Output voltage is in the required range.
FAN OK Green On Power supply internal fan is operational.
— — Off Power supply internal fan is not operational.
Power (front
panel)
Green Steady Installed power supplies are functioning normally.
Table 8-2 Cisco SCE 8000 Operational States (continued)
Cisco SCE 8000
Operational Status Description Status LED State
